Cheese Pipes Straightening Machine
Cheese Pipes Straightening Machine
This innovative product will certainly give you relief from a terrific problem of bend and disturbed cheese pipes. It corrects the inner dia. of your disturbed cheese pipe and you can Re-Use it.
It takes just 1/3 minute to correct one cheese pipe.
Technical Specifications:
| No. of Cylinders | 1 no. main cylinder |
| Working Pressure | 50 kg/cm2 |
| Stroke | 300 mm |
| Approach Speed | 17 mm/sec |
| Return Speed | 26 mm/sec |
| Approx. Time for 300 mm travel | 18 sec |
| Electric Motor | 0.75 KW / 1 hp |
| Oil Reservoir | 30 litres |
| Oil Required | 27 litres (Encli-68, Harmony-68) |
| Operation | By lever operated valve (Polyhydrone) |
| Pump | Dowty. / Rexworth |
| Cylinder Seals | Techlon (Italy) / Markel (Germany) |
